Thursday, March 12, 2009

The Printmaking Process: Pasta Machine Printing at Lillstreet Art Center

This winter I’ve been taking the Intermediate / Advanced Printmaking Workshop at Lillstreet Art Center in the Hummingbird Press Studios. We’ve been working mainly with the etching process, which involves drawing on a protected metal plate, immersing the plate in a chemical bath to “etch” or cut the drawing into the plate, cleaning and then inking the plate, and, finally, printing on paper.


Instructor Julian (left) and students Maya and George
working at the print table



Julian helping Maya (turning the press wheel) with her
chine collé etching (putting Japanese paper on a print)



Examining the print



Student work this semester (left to right)
Light, No Starch by George Bodmer
The Magician by Amy A. Rudberg
Organic Object Series by Maya Durham
Goddess Series by Diana Kast


Our instructor, Julian Cox, who is an artist, printmaker, and director of One Horse Press (the printmaking department of Evanston Art Center), has lived and worked in the Chicago area for the past 20 years. He teaches printmaking classes at One Horse Press and the Lillstreet Art Center. Today, he demonstrated printing with a hand-cranked pasta machine. He suspects he may be the very first person to have ever printed with a pasta machine.

Printing with a Pasta Machine


    Materials:

    - Hand-cranked pasta machine (Imperia brand or whatever is available)


    Clamp the pasta machine to a flat surface.


    - Soft, resilient printmaking paper (Graphic Chemical heavyweight paper or Rives BFK), measuring about 4¾ inches by 5½ inches

    - Felt pad, 1/16 inch (obtained from a printmaking supplier or a felt blanket used under a Christmas tree)

    - Etching ink (tube of Renaissance Black Etching Ink or similar ink obtained from a printmaking supplier)

    - Several small etched plates that will fit in your pasta machine (about 2½ inches long by 3 inches wide). Copper or zinc plates are generally used.


    Steps:

    1. Tear paper to the correct size and soak in water for at least 10 minutes.

    2. Crank the felt about 1 inch into the machine.



    3. To test embossment, set the machine to No. 3 to start. Put the etched plate on top of a piece of dry paper, and then put the layers on the felt (plate facing you) and run them through the machine. Push the layers through the rollers with one hand as you crank the machine.


    Use setting No. 3 to start
    and adjust as necessary.



    Put the image side of the plate down and
    centered closer to one end of the paper.



    Crank the machine and start feeding the end with
    the plate closer to one end of the paper.
    Push the layers down with your other hand.



    Write notes on your embossed paper.


    4. Once the desired embossment is achieved, ink and wipe your etching plate, and blot the printing paper.


    Ink the plate with black etching ink and wipe
    excess ink with a tarlatan (stiffened fabric).



    Blot the soaked paper between blotting paper with
    a rolling pin or use towels.


    5. Repeat the process of feeding the layers of plate (image side down, plate facing you, and closer to one end of the paper)and blotted paper through the machine.


    Be ready to catch the plate and printed image as
    they are released from the machine.


    6. Tear off any excess paper. The printed image can be dried between sheets of paper with a weight on top so the print dries flat.


    Plates on top and prints below



Julian is the head juror for Hand Made Prints, a show presented by One Horse Press, on Saturday, March 28th, running concurrently with the Southern Graphics Council (SGC) Conference. One Horse Press is located at the Noyes Cultural Arts Center, 927 Noyes Street, Evanston, IL. Gallery hours: Monday-Sunday, 10 a.m. to 6 p.m. Phone: 847.448.8260.

Tom Lucas, the founder and director of Hummingbird Press, is part of the group exhibition The Ceramic Print, running concurrently with the SGC Conference, in the Lillstreet Gallery at 4401 N. Ravenswood Avenue in Chicago. Office/Gallery Hours: M-Th:10-7:30 p.m., F-Sa:10-6 p.m., Su:10-5 p.m. Phone: 773.769.4226.


Photo Credit: All photos by Amy A. Rudberg unless otherwise indicated.
